SGFS120 BS Engine Cutting Cutter

Short Description:

Features:

●  The concrete cutter is well designed in structure for easy maintanance

● C&U bearing are adopted, and the key components are of alloy steel material and heat treatment, which prolongs the lifetime, making it anti-abrasion

● ODM design available, the water tank can be changed to platstic type

● Self propelling type available as an option choice

● High intensity belt for stable cutting performance

● Gasoline road cutting machine manufacturer

● Powerful, premium material, solid material, safe and worry-free, trustworthy

● Variety of brand engines can be choosen

● Easy to operate, for safety, a belt protection shell is added

● Rubber material wheels better wear resistant for easy transportation

● Diamond material high hardness cutting blade

● Laser welded blade for reinforced concrete, fast cutting


Product Detail

Technical Data

Model SGFS120
Weight kg 42
Blade Diameter mm 300-350
Dia.of Blade Aperture mm 25.4/27/50
Max.Cutting Depth mm 80
Cutting Blade Speed rpm 3150
Depth Adjustment  Handle Rotation
Driving  Manual Push
Water Tank Capacity  L 13
Sprinkling System Gravity fed
Diamension mm 850*460*710
Engine Power Output HP 5,7

Product Details Display

BS engine cutting cutter Concrete Cutter (1)
BS engine cutting cutter Concrete Cutter (2)
BS engine cutting cutter Concrete Cutter (3)
BS engine cutting cutter Concrete Cutter (4)
BS engine cutting cutter Concrete Cutter (5)
BS engine cutting cutter Concrete Cutter (6)
BS engine cutting cutter Concrete Cutter (7)
BS engine cutting cutter Concrete Cutter (8)
BS engine cutting cutter Concrete Cutter (9)
