Customized Rental Silent Australia Standard Type 300kVA Diesel Genset Set Powered By Cummins Diesel Engine NTA855-G1B with Stamford Alternator HCI444D, Diesel generator manufacturer in China.

Short Description:

Product Features:

—Improved advanced air flow and ambient temperature design which assures the generator can perform its utmost capability both at 100% prime and 110% emergency standby use
—Customized built-in high performance residential muffler minimizes the noise level
—Top lifting points as standard feature
—Forklift pockets and eyelets as standard feature
—External robust steel lockable fuel inlet with electrical fuel gauge as standard feature
—User-friendly external power outlet flap
—Environmental-friendly fully bunded base fuel tank assures no oil or coolant spills onto the ground
—Earth strap fitted on all canopy doors to assure safety
—The canopy adopts a holistic disassembly structure with large size doors to assure the convenience for daily check and maintenance
—High quality outdoor powder coating to strictly protect against rusty, corrosion and ultraviolet radiation

Send email to us

Product Detail

detail exploded view

Product Parameters

Genset Main Technical Data:

Genset Model

SRT300CES

Prime Power(50HZ)

240kW/300kVA

Standby Power(50HZ)

264kW/330kVA

Frequency/Speed

50Hz/1500rpm

Standard Voltage

240V/415V

Voltage Available

220V/380V

Phases

Three phases

reaction for frequency and voltage @ 50% load

in 0.2 S

Regulation accuracy

adjustable,normally 1％

(1) PRP: Prime Power is available for an unlimited number of annual operating hours in variable load applications, in
accordance with ISO8528-1. A 10% overload capability is available for a period of 1 hour within 12-hour period of
operation. In accordance with ISO 3046-1.
(2) ESP: The Standby Power Rating is applicable for supplying emergency power in variable load applications for
up to 200 hours per year in accordance with ISO8528-1. Overload is not allowed.

Cummins Engine Data:

Manufacturer

CUMMINS

Model

NTA855-G1B

Engine speed

1500rpm

--------------------Prime power

283kW

--------------------Standby power

321kW

Type

In line 4-cylinder 4-stroke

Aspiration

Turbocharged & aftercooled

Governor

Electrical

Bore * Stroke

140*152mm

Displacement

14L

Compression ratio

14.0:1

Oil Capacity

38.6L

Coolant capacity

63.9L

Starting Voltage

24V

Fuel consumption(g/KWh)

210

Alternator Data:

Model

HCI444D

Prime power

240kW/300 kVA

Standby power

264kW/ 330 kVA

AVR model

SX460

Number of phase

Power factor (Cos Phi)

0.8

Altitude

≤ 1000 m

Overspeed

2250Rev/Min

Number of Pole

Insulation class

Voltage regulation

±0.5%

Protection

IP 23

Total harmonics (TGH/THC)

< 4 %

Wave form : NEMA = TIF

< 50

Wave form : I.E.C. = THF

< 2%

Bearing

single

Coupling

Direct

Efficiency

84.9%

Silent Type Diesel Gensets Specification:

◆ Original CUMMINS diesel engines,

◆ Stamford brand brushless alternators,

◆ LCD control panel,

◆ CHINT breaker,

◆ Batteries and charger equipped,

◆ 8 hours fuel tank base,

◆ Sound attenuated canopy with residential muffler and exhaust bellows,

◆ Anti-vibration mountings,

◆ 50℃ Radiator c/w Piping Kit,

◆ Parts book and O&M Manual,

◆ Factory test certificate,

Product Display

Standard configuration

*Engine system

*Heavy duty diesel engine
*Four stroke, water cooled
*12V and 24V stater and charge alternator
*Cooling radiator and fan
*Maintenance free battery including ract and cable
*Flexible fuel connection hoses and manual oil sump drain valve
*Exhaust silencer
*Machinery or electronic governing
*Fuel injection pump
*Electric motor starting system
*Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
*Low discharge, and low fuel consumption
*Installed conveniently and maintain easily

*Alternator system

*Brushless, single bearing, flexible disc
*Insulation class: H
*Protection class: IP23
*Self-exciting and Self-regulation

*Canopy

*All canopy designed with modular principles
*All metal canopy parts painted by electrostatic polyester power paint
*Soundproof design ensure that the noise level be controlled in small scope
*Convenient to lift and move
*Easy to maintenance and operate

*Base Frame

*Base frame including position for forklift and crane
*Integral fuel tank
*Daily fuel tank continuously supply for 8-24 hours
*Fuel tank easy to maintain and clean
*Anti-vibration pads are flexed between engine and alternator.

* Control system

Controller Brand: Deepsea , ComAp, Smartgen
Control Panel: English interface,LED screen and touch buttons.
*Control, monitor and protect the Generator Set including:
*High water temperature
*Low oil pressure
*Over and under speed
*Over current
*Under/Over generator voltage
*Start and stop failure
*Low and high battery voltage
*Charge fail
*Emergency stop

Warranty

Running 1000 hours / 12months or 15months from shipment (which comes first)
Improper operation and maintenance will not be covered by the warranty.
